Advanced OEM Pipetting Module

Innovative self-contained pipettor with pressure-based design. Improves pipetting flexibility. Infinite volume range. Compact and lightweight design, allows a 9 mm tip-to-tip distance. Enhances reliability, reduces maintenance. Frictionless operation with no pistons, minimizing wear and tear. Tubeless design enabled by an internal air pump. Cost-efficiency, premium performance without the premium price tag.

Request Pricing
IMI Life Sciences

Receive your quote directly from the manufacturer.

Ease of Use
After Sales Service
Value for Money
Be the first to leave a review

OEM Pipetting modules to simplify your system design

Simplify your fluidics design with the smallest, self-contained pipetting module available without compromising your system's performance.

Save space, weight, and cost

  • Now with a user-friendly tip-eject option.
  • No external pressure source is required.
  • Units can be mounted on 9 mm centers.
  • 40% of the size and 25% of the weight of current technology.
  • Increase your dynamic dispense range from uL to mL in a single device.
  • Closed loop pressure control (tunable PID) enables liquid level, tip, clog and bubble detection.

Our solution

We have developed a fully self-contained pipetting module that opens new possibilities in liquid handling. Precision dispense performance that matches or improves upon the performance of other pipettors while greatly reducing size and weight.

Leading performance in a compact package.

Dimensions: 97.2 mm x 16.9 mm x 72.1 mm (3.83 in x 0.67 in x 2.84 in)
Width at tip mandrel: 8.95 mm (0.35 in)
Weight: 100g (3.5 oz)

Precision:

  • 200 to 1000 µL: < 1% CV
  • 50 to 199 µL: < 2.5% CV
  • 10 to 49 µL: < 3% CV
  • 5 to 9 µL: < 5% CV
  • 1 to 4 µL: < 10% CV
