Digital Multimeter PCE-123

PCE InstrumentsAvailable: Worldwide

Digital, electrical, current, voltage or process calibrator, tester or multimeter for simulation and measurement of standardized electrical signals / control signals as well as frequencies and temperature

The supplier does not provide quotations for this product through SelectScience. You can search for similar products in our  Product Directory.

Average Rating 4.0

|2Scientists have reviewed this product

Ease of Use
After Sales Service
Value for Money
Write your own review

Overall it is a good product.



Average Rating 4.0

Application Area:

We use this handy machine for the simulation and measurement of electric signals in our lab

It is very easy to operate with an automatic ramp function. This device has very high accuracy and provides very precise results. I love to work on this device because of its simplicity and precision.

Review Date: 23 Jul 2022 | PCE Instruments

Good product to use, go for it



Average Rating 4.0

Application Area:

For Measurement of Standardized Electrical Signals & Control Signals

The Digital Multimeter by PCE is a very good, easy-to-use, and useful handy digital multimeter. This instrument provides a 1 to 62,500Hz frequency range and our work consists of the range of 200 to 1650Hz so it can be useful for our research work as well. Its weight is just 330 gm which is very low and easy to handle or carry anywhere in the facility for research work. It occupies less space. We also use this tool for control signals measurements. The support team is very cooperative. That's why I suggest this instrument.

Review Date: 2 Apr 2022 | PCE Instruments

The PCE-123 is a network-independent multifunction calibrator used to test and calibrate a variety of parameters of controllers and measuring instruments. Offering a high level of accuracy for an affordable price, this easy-to-use calibrator provides electrical (mA, mV, V and frequency in Hz) and temperature (in °C or °F) output signals, making the calibrator useful in a wide range of applications.

The calibrator also has automatic step and ramp functions as well as the possibility to pre-select the output signal steps (0 … 100 %) by using the arrow keys and to directly specify an output value (e. g. 13.8 mA). Operation via the keypad is very easy and intuitive. The PCE-123 multifunctional calibrator is an important tool in any electronics workshop as well as in any measuring and control department in trade, industry and automation.


- 4 to 20mA (1kΩ, 24V power)
- 0 to 100.00 mV / 0 to 1,0000V / 0 to 12,000V
- Type-K, J, E, T temperature thermocouple sensors (°C or °F)
- Frequency range 1 to 62,500Hz
- Basic accuracy 0.025 %
- Easy operation via keypad
- Automatic ramp function
- Selectable between 0 to 20mA/ 0 to 24mA
- Input 0 to 100% (mA, mV, V )
- Alarm beep 'open' (mA) or 'short circuit' (mV, V)
