Unistat 405w
Hydraulically sealed circulator with atmospheric open expansion tank for open baths and external closed systems High system performance (watt/litre) due to minimized internal volume No HTF vapour and no moisture absorption because the expansion tank is thermally passive For external open baths the expansion tank will be blocked off. This means that the thermostat is atmospherically sealed and can be located below or above…
The supplier does not provide quotations for this product through SelectScience. You can search for similar products in our Product Directory.
- Hydraulically sealed circulator with atmospheric open expansion tank for open baths and external closed systems
- High system performance (watt/litre) due to minimized internal volume
- No HTF vapour and no moisture absorption because the expansion tank is thermally passive
- For external open baths the expansion tank will be blocked off. This means that the thermostat is atmospherically sealed and can be located below or above the level of the application.
- Plug & Play Technology, microprocessor controlled, with integrated programmer, external sensor and removable control unit for remote control
- Adjustable overtemperature protection according to DIN 12876.
New: Expanded temperature range -45°C...+250°C, self-optimizing adaptive control (TAC), self-optimizing adaptive control, colour TFT touchscreen, simple operation, Huber-Software SpyLight (PC).
Extended connection possibilities via exchangeable Interface module: ComBox (Namur Standard): RS232, RS485 bidirectional, control input 24V or contact (release), 3 analogue outputs 4-20mA, 1 analogue input 4-20mA, control output 30V/100mA volt free, can be configured as alarm contact.
