Top 5 Nanomaterial Applications and Analyses
19 Oct 20141. Single Particle Analysis of Nanomaterials Using the Agilent 7900 ICP-MS
This application note evaluates the performance of the Agilent 7900 ICP-MS for the measurement of individual NP peak signals. The 7900 ICP-MS features a new orthogonal detector system that has a fast integration time of 100 µs, zero settling time between TRA readings, and an overall acquisition speed in TRA mode that is 30x faster than the 7700x, permitting fast transient signal measurement.
2. Automated Particle Size with Zetasizer NanoSampler from Malvern Instruments
Watch this video to learn about the Zetasizer NanoSampler from Malvern. This sample delivery system ensures highly precise and reproducible automated loading of samples into your Zetasizer Nano for particle size measurements. The NanoSampler adds automation and unattended operation in a versatile, compact package, maximizing the productivity of your Zetasizer Nano.
This application note explores the capability of modern ICP-MS to measure the key characteristics of metal manufactured nanoparticles. ICP-MS is rapidly becoming the elemental measurement technique of choice for assessing the manufacturing and environmental lifecycle of engineered nanoparticles.
This application note demonstrates how a combination of SPR and QMC can be used to measure the amount of bound water in interfacial layers. The same type of experiments can be used to estimate the kinetics of adsorption.
5. Fabricating Metallic Nanoclusters for Use in Photonics, Medical and Electronic Applications
NanoInk has harnessed the ability of Dip Pen Nanolithography® (DPN®) technology to deposit materials with nanoscale precision in order to develop a technique for fabricating metallic nanoclusters. In this application note, NanoInk’s nanolithography systems were used to pattern sub-micron sized droplets of a mixture of metal salt in P2VP-PEO onto a SiO2substrate.
