Human and Mouse Phospho-EGFR (Y1068) ELISA
RayBio® Human and Mouse Phospho-EGFR (Y1068) ELISA Kit. This assay semi-quantitatively measures phosphorylated EGFR (Tyr1045) and Total EGFR in lysate samples.
Antigen Information
Accession Number: P00533
Gene ID: 3236
Gene Symbols: EGFR; ERBB; ERBB1; HER1
Protein Name & Synonyms: Epidermal growth factor receptor (EC 2.7.10.1) (Proto-oncogene c-ErbB-1) (Receptor tyrosine-protein kinase erbB-1)
Assay Format
Pathway: HER/ErbB Signaling
Specificity: The antibody pair provided in this kit recognizes human Phospho-EGFR (pTyr1068).
Number of Targets Detected: 1
Species Detected: Human; Mouse
Compatible Sample Types: Cell Lysates; Tissue Lysates
Design Principle: Sandwich-based
Method of Detection: Colorimetric
Quantitative/Semi-Quantitative: Semi-Quantitative
Solid Support: 96-well Microplate
Product Specifications
Size: 1, 2, or 5 x 96-Well Strip Microplate Kit
Product Features
- Rapidly measure phosphorylated protein in lysates
- Screen numerous different cell lysates without performing a Western Blot analysis
- Minimal hands-on time, convenient, and non-radioactive material
Application Notes
Kit Components
- Pre-Coated 96-well Strip Microplate
- Wash Buffer
- Anti-Phospho Antibody
- HRP-Conjugated Secondary Antibody
- Assay Diluent
- TMB One-Step Substrate
- Stop Solution
- Lysis Buffer
- Positive Control Sample
Other Materials Required
- Distilled or deionized water
- 100 ml and 1 liter graduated cylinders
- Tubes to prepare sample dilutions
- Protease and Phosphatase inhibitors
- Precision pipettes to deliver 2 µl to 1 ml volumes
- Adjustable 1-25 ml pipettes for reagent preparation
- Benchtop rocker or shaker
- Microplate reader capable of measuring absorbance at 450 nm
Protocol Outline
Prepare all reagents and samples as instructed in the manual.
Add 100 µl of sample or positive control to each well.
Incubate 2.5 h at RT or O/N at 4 °C.
Add 100 µl of prepared primary antibody to each well.
Incubate 1 h at RT.
Add 100 µl of prepared 1X HRP-Streptavidin to each well.
Incubate 1 h at RT.
Add 100 µl of TMB One-Step Substrate Reagent to each well.
Incubate 30 min at RT.
Add 50 µl of Stop Solution to each well.
Read at 450 nm immediately.
Storage/Stability
Upon receipt, the kit should be stored at -20 °C. Please use within 6 months from the date of shipment. After initial use, Wash Buffer Concentrate (Item B), Assay Diluent (Item E), TMB One-Step Substrate Reagent (Item H), HRP-Streptavidin (Item G), Stop Solution (Item I) and Cell Lysate Buffer (Item J) should be stored at 4 °C to avoid repeated freeze-thaw cycles. Return unused wells to the pouch containing desiccant pack, reseal along entire edge and store at -20 °C. Reconstituted Positive Control (Item K) should be stored at -70 °C.
