NRS-7000 Series Raman Spectrometer
The performance and functions expected on a micro-Raman spectrometer are all provided with the NRS-7000 series Raman systems, assuring consistent performance for rapid acquisition of high quality data with automated system control and minimal optical adjustments. For application expansion, an automated multi-grating turret, 2 internally mounted detectors and a maximum of 8 lasers ranging from the UV through the NIR are capable…
The supplier does not provide quotations for this product through SelectScience. You can search for similar products in our Product Directory.
The performance and functions expected on a micro-Raman spectrometer are all provided with the NRS-7000 series Raman systems, assuring consistent performance for rapid acquisition of high quality data with automated system control and minimal optical adjustments.
For application expansion, an automated multi-grating turret, 2 internally mounted detectors and a maximum of 8 lasers ranging from the UV through the NIR are capable of integration with the instrument system, all optical components are PC controlled for maximum flexibility with minimum user interaction.
Features
- Research-grade model assuring high spectral quality
- Exceptional wavenumber accuracy with a high-precision rotary-encoder direct drive mechanism
- Low wavenumber measurement (NRS-5200/7200)
- Auto-alignment of microscope laser introduction optics and Raman scattering light path
- Wavenumber calibration using an integrated Ne lamp
- Unique Dual Spatial Filter (DSF) for higher spatial resolution than conventional confocal optics
- Patented Spatial Resolution Image (SRI) function for simultaneous observation of sample image, laser spot and aperture image
- Full range of options including macro-Raman measurement unit and fiber optic probes
